Bruker IVDr 600MHz NMR System

Our Bruker IVDr 600MHz NMR system is fully-automated and designed specifically for lipidomics- and metabolomics-based studies of:

• Cells
• Organ tissue (e.g. liver, muscle, intestines, tongue, and tumor)
• Biological fluids (e.g. urine, serum, cerebral spinal fluid, plasma, amniotic fluid and saliva)
• Exhaled breath collected from human subjects or animal models

The Bruker IVDr, a top-of-the-line spectrometer, is capable of running most contemporary homonuclear, heteronuclear one and two-dimensional pulse sequences, using pre-designed software, and is equipped with a 96-well SampleJet auto-sampler unit that renders the NMR system fully-automated.

The Bruker spectrometer is equipped with a 5mm triple resonance conventional probe, which allows for routine acquisition of 1D and 2D 1H-1H correlations as well as 1D 13C and 2D 1H-13C correlations.

Low-Temperature SpeedVac Concentrator

Operation Mode

• Lyopholizer
• SpeedVac centrifuge

Centrifuge

• Operates from RT 80°C
• Multi-sample rotor

Trap

• Cold trap (-105°C)
• Liquid nitrogen trap (-196°C)

Minilys (Sample Homogenizer)

• Room temperature homogenizer
• 3 speeds
• Up to 4 minute run
• Various bead materials – steel, ceramic
• 0.5, 2 or 7 mL same tube size
• Same types: wet, dry, liquid
• Minimum sample loss

Tube Writer

Automated Tube Labeler

• Operates on range of tube types
• Test tubes
• Standard centrifuge tubes
• Microplates
• Microscope slides

pH Titration System

Automated pH Titrations

• Small sample size (min. 300 µL)
• Small volume change
• Starting from 0.01 µL
• Accurate to 0.02 units of target pH
• More accurate and consistent NMR data for pH sensitive assays

Cryomil (Cryogenic Tissue Homogenizer)

Cryo-Tissue Homogenizer

• Operates at -196°C (LN2)
• Wide range of sample size
• Up to 99 minute run
• Steel ball mill
• Up to 50mL jar size
• Applicable to large sample size
• Sample types: dry, wet, frozen
